UC SERIES

The UC SERIES offers 4K resolution with vibrant colors, high brightness, and flicker-free playback, ensuring stunning visuals in any setting.

4K high-definition resolution

Exquisite picture, full color, and realistic reproduction of image quality

High brightness and high-definition display

Every detail is clearly visible, the effect is natural, the picture is clear, and the colors are bright

High refresh rate without flicker

Smooth screen playback, no trailing phenomenon – stable screen

Specification

DESCRIPTION	*OUTDOOR 320160 REAR SERVICE SERIES**								UNITS
PIXEL PITCH	P2.5	P3.076	P4	P5	P5.926	P6.667	P8	P10
BRIGHTNESS	≥5500	≥5500	≥5500	≥5500	≥5500	≥5500	≥5500	≥6500	Cd
REFRESH RATE	1920 or 3840	1920 or 3840	1920 or 3840	1920 or 3840	1920 or 3840	1920 or 3840	1920 or 3840	1920 or 3840	Hz
SERVICE	Front or Rear	Front or Rear	Front or Rear	Front or Rear	Front or Rear	Front or Rear	Front or Rear	Front or Rear
SCAN	1/16	1/13	1/10	1/8	1/7	1/6	1/5	1/2	Scan
DRIVER IC	ICN2037/ICN2153	ICN2037/ICN2153	ICN2037/ICN2153	ICN2037/ICN2153	ICN2037/ICN2153	ICN2037/ICN2153	ICN2037/ICN2153	ICN2037/ICN2153
LED TYPE	SMD1415	SMD1415	SMD1921	SMD1921	SMD2727	SMD2727	SMD3535	SMD3535	SMD
MODULE SIZE	320*160	320*160	320*160	320*160	320*160	320*160	320*160	320*160	MM
MODULE RESOLUTION	160*160	104*52	80*40	64*32	54*27	48*24	40*20	32*16	Dots
CABINET SIZE(W×H)	960*960	960*960	960*960	960*960	960*960	960*960	960*960	960*960	MM
CABINET MATERIAL	Iron or Alu	Iron or Alu	Iron or Alu	Iron or Alu	Iron or Alu	Iron or Alu	Iron or Alu	Iron or Alu
CABINET CONFIGURATION	3*6	3*6	3*6	3*6	3*6	3*6	3*6	3*3	Pcs
CABINET RESOLUTION	384*384	312*312	240*240	192*192	162*162	144*144	120*120	96*96	Dots
CABINET WEIGHT	26	26	26	26	26	26	26	26	Kg
VIEWING ANGLE	H:160 V:140	H:160 V:140	H:160 V:140	H:160 V:140	H:160 V:140	H:160 V:140	H:160 V:140	H:160 V:140	Kg
CERTIFICATIONS	CE,RoHS,CCC	CE,RoHS,CCC	CE,RoHS,CCC	CE,RoHS,CCC	CE,RoHS,CCC	CE,RoHS,CCC	CE,RoHS,CCC	CE,RoHS,CCC
OPERATING POWER	90-240	90-240	90-240	90-240	90-240	90-240	90-240	90-240	Volts
OPERATING FREQUENCY	50-60	50-60	50-60	50-60	50-60	50-60	50-60	50-60	Hz
POWER CONSUMPTION	750	750	750	750	750	650	750	750	W/m²
OPERATING TEMPERATURE	20min/+45max	20min/+45max	20min/+45max	20min/+45max	20min/+45max	20min/+45max	20min/+45max	20min/+45max	W/m²
STORAGE TEMPERATURE	20min/+60max	20min/+60max	20min/+60max	20min/+60max	20min/+60max	20min/+60max	20min/+60max	20min/+60max	°C
OPERATING HUMIDITY	20%min/70%max	20%min/70%max	20%min/70%max	20%min/70%max	20%min/70%max	20%min/70%max	20%min/70%max	20%min/70%max
STORAGE HUMIDITY	30%min/85%max	30%min/85%max	30%min/85%max	30%min/85%max	30%min/85%max	30%min/85%max	30%min/85%max	30%min/85%max
LIFE SPAN	100000	100000	100000	100000	100000	100000	100000	100000	Hours
VIDEO INPUT	DVI HDMI	DVI HDMI	DVI HDMI	DVI HDMI	DVI HDMI	DVI HDMI	DVI HDMI	DVI HDMI
PROTECTION LEVEL	Front IP65Back IP54	Front IP65Back IP54	Front IP65Back IP54	Front IP65Back IP54	Front IP65Back IP54	Front IP65Back IP54	Front IP65Back IP54	Front IP65Back IP54
DISPLAY RESOLUTION	160000	105688	62500	40000	28504	22477	15625	10000	Pixels/m²
BRIGHTNESS CONTROL	256 steps Autoor manual	256 steps Autoor manual	256 steps Autoor manual	256 steps Autoor manual	256 steps Autoor manual	256 steps Autoor manual	256 steps Autoor manual	256 steps Autoor manual
GRAY SCALE(Bit)	16-bit	16-bit	16-bit	16-bit	16-bit	16-bit	16-bit	16-bit
